When mirrorless cameras first appeared, one of their main attractions was supposed to be decreased size and weight. Indeed Olympus and Panasonic’s original joint press release announcing the birth of Micro Four Thirds, the world’s first mirrorless system, declared that it would enable users to ‘take advantage of significantly more compact lenses, particularly in the wide-angle and high-power zoom range’. The Olympus M.Zuiko Digital ED 12-45mm F4 Pro zoom positions itself as one of the best Micro Four Third lenses.

Olympus M.Zuiko Digital ED 12-45mm f/4 Pro at a glance:

  • Price: $408 / £450
  • Filter diameter: 58 mm
  • Lens elements: 12
  • Groups: 9
  • Diaphragm blades: 7
  • Min Focus: 0,12 m
  • Weight: 254 g / 9 ounces
  • Lens Mount: Micro Four Thirds
  • Fixed aperture value across the entire zoom range
  • OM Digital Solutions
Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens mounted on OM Micro Four Thirds Camera

Cosmetically, the 12-45mm f/4 is instantly recognisable as on of Olympus’s Pro-line lenses

As things have progressed, though, this goal often seems to have been lost by the wayside, to the extent that while the latest full-frame mirrorless cameras may be smaller than their DSLR counterparts, their lens systems have generally become larger.

Reduced size and weight is still a key benefit of smaller-sensor cameras, however, and Olympus/OM Digital Solutions seems to be particularly intent on maximizing this advantage. The M.Zuiko Digital ED 12-45mm f/4 Pro came out in February 2020 and at the time of launch, the firm claimed it was the world’s smallest and lightest zoom lens with a constant maximum aperture. It’s designed to provide users with premium optics and tough, weather-sealed build quality in a tiny package that’s just 7cm long and weighs 254g.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens mounted on OM-D EM5-III Micro Four Thirds Camera

The Olympus 12-45mm F4 Pro is unusually small for a premium zoom

With a versatile zoom range equivalent to 24-90mm in full-frame terms, it looks like an ideal complement to the E-M5 III or the more recent OM System OM-5 although the $500 / £599 price tag could be a tough sell for a lens this small.

Olympus M.Zuiko Digital ED 12-45mm f/4 Pro: Features

Olympus says that the 12-45mm f/4 employs an optical formula based on its existing M.Zuiko Digital ED 12-40mm F2.8 Pro (replaced by the M.Zuiko Digital ED 12-40mm F2.8 Pro II with uprated weather sealing in February 2022) which is an enticing prospect given that this one of the finest standard zooms available. Detailed examination shows that the new lens’s 12-element, 9-group formula is indeed very closely related to its sibling’s 14-element, 9-group design.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro and Olympus 12-40mm 2.8 Pro lens side by side

Olympus has based the 12-45mm f/4 Pro (left) on the excellent 12-40mm f/2.8 Pro

It makes similarly lavish use of special glass, too, incorporating aspheric, dual super-aspheric (DSA), high refractive index (HR), super-high refractive index and Extra-low Dispersion (ED) elements into its construction, in order to minimise optical aberrations. Meanwhile Olympus’s Zero coating is applied to suppress flare and ghosting. It’s difficult to think of another small zoom with a similarly ambitious design.

As part of the premium Pro series, the 12-45mm F4 is also designed to be dust-, splash- and freeze-proof, with a range of seals protecting vulnerable points such as the front element, manual-focus and zoom rings, and mount.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens, lens mount, and sealing

A seal around the lens mount blocks dust or water from getting into the camera

One feature it gives up relative to the firm’s other Pro zooms, though, is the push-pull focus clutch; instead it employs a simple, continuously rotating electronic manual focus ring. This drives a single focusing element that’s placed towards the rear of the lens, which also affords rapid, silent autofocus.

The aperture diaphragm employs seven curved blades in a bid to provide attractive background blur. However with the f/4 maximum aperture giving equivalent depth-of-field characteristics to f/5.6 on APS-C and f/8 on full-frame, you won’t see a huge degree of blur, except during close-up shooting.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens

The 12-45mm f/4 employs a relatively small 58mm filter thread

But here the lens has another trick: its minimum focus distance ranges from 12cm at wideangle to 23cm at telephoto, maintaining an impressive 0.5x equivalent magnification across the entire zoom range. It’s also compatible with the focus bracketing and stacking functions built into Olympus’s recent models, which allow depth of field to be extended without sacrificing background blur.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens with lens hood, mounted on OM-D EM5-III Micro Four Thirds Camera

A bayonet fit, petal-type lens hood is included in the box

In the box you’ll find a simple bayonet-fit plastic lens hood, which reverses neatly over the barrel for storage, but lacks any locking mechanism to hold it in place. The accessory thread measures just 58mm, which enables the use of relatively inexpensive filters.

Olympus M.Zuiko Digital ED 12-45mm f/4 Pro: Build and Handling

In terms of design, the 12-45mm f/4 is immediately recognisable as a Pro-series optic. It employs a familiar-looking all-metal barrel, with finely ridged grips to the focus and zoom and focus rings. The latter falls naturally to your fingers, and both operate super-smoothly. But there’s no space for a customisable L.Fn button on the lens’s barrel.

Olympus M.Zuiko Digital ED 12-45mm F4 Pro lens mounted on OM-D EM5-III Micro Four Thirds Camera

The Olympus 12-45mm f/4 Pro handles well on the E-M5 III, despite its tiny size

With its compact size and light weight, the 12-45mm is a perfect complement to Olympus’s smaller cameras such as the E-M10 and E-M5 series. Its Micro Four Thirds mount means it’ll also fit onto Panasonic cameras, and should work very nicely with the likes of the G80, G90 and GX9. But as it doesn’t include optical stabilisation, it’s not such a great match to older or smaller bodies that aren’t equipped with in-body stabilisation.

Olympus zooms compared

When the original OM-D E-M5 appeared in 2012, its kit zoom was the M.Zuiko Digital ED 12-50mm f/3.5-6.3 EZ. This lightweight, versatile, weather-sealed optic featured an unusual switchable manual/electronic zoom and a dedicated macro setting, but it was optically mediocre.

Olympus 12-50mm f/3.5-6.3, 12-40mm f/2.8, and 12-45mm f/4 side-by-side

Olympus 12-50mm f/3.5-6.3, 12-40mm f/2.8, and 12-45mm f/4 side-by-side

Thankfully Olympus users didn’t have to wait too long for the stellar 12-40mm f/2.8, which became the natural fit to the E-M5 Mark II. But while not exactly large, it’s almost twice the weight of the 12-50mm.

Olympus 12-50mm f/3.5-6.3 on E-M5; 12-40mm f/2.8 on E-M5 II; 12-45mm f/4 on E-M5 III, all with hoods fitted

Olympus 12-50mm f/3.5-6.3 on E-M5; 12-40mm f/2.8 on E-M5 II; 12-45mm f/4 on E-M5 III, all with hoods fitted

The 12-45mm essentially offers a similar concept to the 12-50mm, but with vastly better optics. Paired with the E-M5 Mark III or the OM-5, the combination weighs just 668g, a reduction of over 20% compared to the E-M5 Mark II with the 12-40mm, and just 32g heavier than the original E-M5 with the 12-50mm. The 12-45mm is also the shortest of the three by 13mm, making it the easiest to pack into a small bag.

For more options have a look at the best Micro Four Thirds lenses.

Olympus 12-45mm f/4 Pro: Autofocus

Turning our attention to focusing, it quickly becomes apparent that the 12-45mm f/4 is pretty much beyond reproach. Tested with a range of cameras from both Olympus and Panasonic, it snaps into focus instantly and silently, with all the accuracy that you’d expect from on-sensor AF. It’s especially impressive on the phase-detection equipped E-M5 Mark III.

Olympus 12-45mm f/4 on E-M5 III, 45mm, 1/100sec at f/4, ISO 400

Manual focus offers an excellent experience, too. Rotating the focus ring can automatically engage your preferred focus aid, such as peaking or magnified view, and its smooth action makes precise focusing a breeze. As a result, I never really missed having a manual focus clutch.

Olympus 12-45mm f/4 Pro: Performance

Given its close relationship to the 12-40mm f/2.8 and 12-40mm f/2.8 II, I had high expectations for the 12-45mm f/4. Thankfully, it doesn’t disappoint. The coronavirus pandemic prevented us from doing our usual studio-based tests, so this review is based on detailed examination of a wide range of images, from both controlled tests and real-world shooting. This reveals that the 12-45mm hasn’t just inherited its larger-aperture sibling’s looks and optics, but also its stellar image quality. In essence, it delivers near-flawless results no matter what you ask of it.

Olympus 12-45mm f/4 Pro on E-M5 III, 13mm, 1/320sec at f/5.6, ISO 200

Tested on the 20MP E-M5 Mark III, the lens provides excellent sharpness from corner to corner. It gives near-indistinguishable results to the original 12-40mm f/2.8 when comparing images shot side-by-side under controlled conditions, with the only discernable difference being that the 12-45mm suffers from just a little softening in the corners at 12mm f/4. But this is only visible when pixel peeping images at 100% on a computer screen, and shouldn’t be a problem in print.

Olympus 12-45mm f/4 Pro on E-M5 III, 12mm, 1/250sec at f/5.6, ISO 200

Overall, I’d happily shoot at any focal length and subject distance, and all apertures from f/4 down to about f/11. But I’d caution against stopping down further, as this always results in excessive diffraction softening on Micro Four Thirds.

Olympus 12-45mm f/4 Pro on E-M5 III, 26mm, 1/30sec at f/11, ISO 800

There’s little to worry about with regards to vignetting, and while some corner darkening can be discernible when shooting evenly toned subjects at 12mm and f/4, it’s not objectionable. Software correction of distortion and lateral chromatic aberration is integrated into Micro Four Thirds, and as a result, you’ll rarely see any colour fringing or bowing of straight lines along the edges of the frame. The only exception is when shooting close-ups at the wide end of the zoom, when some barrel distortion becomes apparent. But if you need such images to be geometrically accurate, simply back off from the subject and zoom in.

Olympus 12-45mm f/4 Pro on E-M5 III, 25mm, 1/125sec at f/5.6, ISO 800

Close-up shooting is of course this lens’s party trick, and one at which it excels. Its impressive minimum focus distance across the entire zoom allows a wide range of creative looks, from expansive backgrounds at wideangle to tighter framing at telephoto.

Olympus 12-45mm f/4 Pro on E-M5 III, 12mm, 1/400sec at f/4, ISO 400

The main practical limitation arises at wideangle, where the working distance to the subject is just a few millimetres from the front element, which makes it difficult to avoid getting in your own light. But again, image quality is really good, and if you shoot wide open at 45mm, it’s also possible to get some very attractive-looking background blur.

Olympus 12-45mm f/4 Pro on E-M5 III, 30mm, 1/160sec at f/4, ISO 200

About the only point of concern is flare when shooting directly into the sun, which can result in loss of contrast and red internal reflection patterns. But you can see this live in the viewfinder when you’re shooting, which can help you to suppress it by such means as tweaking the composition or stopping down the aperture.

Olympus M.Zuiko Digital ED 12-45mm f/4 Pro: Verdict

With the 12-45mm f/4, Olympus has made a stunning small, lightweight standard zoom that’s a more affordable, but equally fine alternative to the 12-40mm f/2.8 and 12-40mm f/2.8 II. It provides a rare combination of ruggedness, portability, and superb image quality, particularly when used in combination with the OM-D E-M5 Mark III. Its remarkable macro capability is the icing on the cake, bringing an extra layer of creativity.

The Olympus 12-45mm f/4 Pro provides a unique combination of advantages

There’s a lot of focus right now on the image quality advantages of larger sensors, but let’s not forget that lenses are an equally important part of the equation, and it’s easier to make top-notch optics for smaller sensors. As a result, you’ll struggle to find another lens quite like this for any other system.

Olympus 12-45mm f/4 Pro on E-M5 III, 45mm, 1/160sec at f/6.3, ISO 200

Probably the lens’s biggest limitation is its f/4 maximum aperture, which affords precious little scope for selective focus effects or manipulating depth of field. If this is important to you, the 12-40mm f/2.8 would be the better choice. Equally for Olympus users who already own and are happy with a 12-40mm f/2.8 or 12-40mm f/2.8 II, there’s no obvious reason to change. However for Micro Four Thirds users who’d like to upgrade their kit lens without adding much bulk, or indeed DSLR users looking to downsize their kit, the 12-45mm f/4 is definitely one to shortlist.
