This is the full spec for the Canon EOS 600D:
Canon EOS 600D full specification, as supplied by Canon UK:
IMAGE SENSOR
Type 22.3 x 14.9mm CMOS
Effective Pixels Approx. 18.0 megapixels
Total Pixels Approx 18.7 megapixels
Aspect Ratio 3:2
Low-Pass Filter Built-in/Fixed
Sensor Cleaning EOS integrated cleaning system
Colour Filter Type Primary Colour
IMAGE PROCESSOR
Type DIGIC 4
LENS
Lens Mount EF/EF-S
Focal Length Equivalent to 1.6x the focal length of the lens
FOCUSING
Type TTL-CT-SIR with a CMOS sensor
AF System/ Points 9 AF points (f/5.6 cross type at centre, extra sensitivity at f/2.8)
AF Working Range EV -0.5 -18 (at 23°C & ISO100)
AF Modes AI Focus
One Shot
AI Servo
AF Point Selection Automatic selection, Manual selection
Selected AF Point Display Superimposed in viewfinder and indicated on LCD monitor
Predictive AF [7] Yes up to 8m
AF Lock Locked when shutter button is pressed half way in One Shot AF mode.
AF Assist Beam Intermittent firing of built-in flash or emitted by optional dedicated Speedlite
Manual Focus Selected on lens, default in Live View Mode
AF Microadjustment No
EXPOSURE CONTROL
Metering Modes TTL full aperture metering with 63-zone SPC
(1) Evaluative metering (linked to all AF points)
(2) Partial metering at center (approx. 9% of viewfinder)
(3) Spot metering (approx. 4% of viewfinder at center)
(4) Center weighted average metering
Metering Range EV 1-20 (at 23°C with 50mm f/1.4 lens ISO100)
AE Lock Auto: In 1-shot AF mode with evaluative metering exposure is locked when focus is achieved.
Manual: By AE lock button in creative zone modes.
Exposure Compensation +/-5 EV in 1/3 or 1/2 stop increments (can be combined with AEB).
AEB 3 shots +/- 2 EV, 1/2 or 1/3-stop increments
ISO Sensitivity [8] AUTO(100-6400), 100-6400 Expandable to H (approx 12800) in 1-stop increments
SHUTTER
Type Electronically-controlled focal-plane shutter
Speed 30-1/4000 sec (1/2 or 1/3 stop increments), Bulb (Total shutter speed range. Available range varies by shooting mode)
WHITE BALANCE
Type Auto white balance with the imaging sensor
Settings AWB, Daylight, Shade, Cloudy, Tungsten, White
Fluorescent light, Flash, Custom.
White balance compensation:
1. Blue/Amber +/-9
2. Magenta/ Green +/-9.
Custom White Balance Yes, 1 setting can be registered
WB Bracketing +/-3 levels in single level increments
3 bracketed images per shutter release.
Selectable Blue/Amber bias or Magenta/ Green bias.
VIEWFINDER
Type Pentamirror
Coverage (Vertical/Horizontal) Approx. 95%
Magnification Approx. 0.85x [4]
Eyepoint Approx. 19mm (from eyepiece lens centre)
Dioptre Correction -3 to +1 m-1 (dioptre)
Focusing Screen Fixed
Mirror Quick-return half mirror (Transmission: reflection ratio of 40:60, no mirror cut-off with EF600mm f/4 or shorter)
Viewfinder Information AF information: AF points, focus confirmation light
Exposure information: Shutter speed, aperture value, ISO speed (always displayed), AE lock, exposure level/compensation, spot metering circle, exposure warning, AEB
Flash information: Flash ready, high-speed sync, FE lock, flash exposure compensation, red-eye reduction light
Image information: Highlight tone priority (D+), monochrome shooting, maximum burst (1 digit display), White balance correction, SD card information
Depth of Field Preview Yes, with Depth of Field preview button.
Eyepiece Shutter On strap
LCD MONITOR
Type Vari angle 7.7cm (3.0″) 3:2 Clear View TFT, approx. 1040K dots
Coverage Approx. 100%
Viewing Angle (horizontally/vertically) Approx 170°
Coating Dual Anti-reflection, anti smudge
Brightness Adjustment Adjustable to one of seven levels
Display Options (1) Quick Control Screen
(2) Camera settings
FLASH
Built-in Flash GN (ISO 100, meters) 13
Built-in Flash Coverage up to 17mm focal length (35mm equivalent: 27mm)
Built-in Flash recycle time Approx. 3 seconds
Modes Auto, Manual flash, Integrated Speedlite Transmitter
Red-Eye Reduction Yes – with red eye reduction lamp
X-sync 1/200sec
Flash Exposure Compensation +/- 2EV in 1/2 or 1/3 increments
Flash Exposure Bracketing Yes, with compatible External Flash
Flash Exposure Lock Yes
Second Curtain Synchronisation Yes
HotShoe/ PC terminal Yes/ –
External Flash Compatibility E-TTL II with EX series Speedlites, wireless multi-flash support
External Flash Control via camera menu screen
SHOOTING
Modes Scene Intelligent Auto, No Flash, Creative Auto, Portrait, Landscape, Close-up, Sports, Night Portrait, Movie, Program AE , Shutter priority AE, Aperture priority AE, Manual, A-DEP
Picture Styles Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Defined (x3)
Colour Space sRGB and Adobe RGB
Image Processing Highlight Tone Priority
Auto Lighting Optimizer (4 settings)
Long exposure noise reduction
High ISO speed noise reduction (4 settings)
Auto Correction of Lens Peripheral illumination
Basic+ (Shoot by ambience selection, Shoot by lighting or scene type)
Creative filters (Grainy B/W, Soft focus, Toy camera, Miniature effect, Fish-eye) – during image Playback only
Drive Modes Single, Continuous, Self timer (2s, 10s+remote, 10s + continuous shots 2-10)
Continuous Shooting Max. Approx. 3.7fps for approx. 34 JPEG images [1], 6 images RAW [2]
LIVE VIEW MODE
Type Electronic viewfinder with image sensor
Coverage Approx. 99% (horizontally and vertically)
Frame Rate 30 fps
Focusing Manual Focus (Magnify the image 5x or 10x at any point on screen)Autofocus: Quick mode, Live mode
Metering Real-time evaluative metering with image sensor
Active metering time can be changed
Display Options Grid overlay, Histogram
FILE TYPE
Still Image Type JPEG: Fine, Normal (Exif 2.30 compliant) / Design rule for Camera File system (2.0),
RAW: RAW (14bit, Canon original RAW 2nd edition),
Digital Print Order Format [DPOF] Version 1.1 compliant
RAW+JPEG Simultaneous Recording Yes, RAW + Large JPEG
Image Size JPEG 3:2: (L) 5184×3456, (M) 3456×2304, (S1) 2592×1728, (S2) 1920×1280, (S3) 720×480
JPEG 4:3: (L) 4608×3456, (M) 3072×2304, (S1) 2304×1728, (S2) 1696×1280, (S3) 640×480
JPEG 16:9: (L) 5184×2912, (M) 3456×1944, (S1) 2592×1456 (S2) 1920×1080, (S3) 720×400
JPEG 1:1: (L) 3456×3456, (M) 2304×2304, (S1) 1728×1728, (S2) 1280×1280, (S3) 480×480
RAW: (RAW) 5184×3456
Movie Type MOV (Video: H.264, Sound: Linear PCM)
Movie Size 1920 x 1080 (29.97, 25, 23.976 fps)
1280 x 720 (59.94, 50 fps)
640 x 480 (59.94, 50 fps)
Movie Length Max duration 29min 59sec, Max file size 4GB
Folders New folders can be manually created and selected
File Numbering (1) Consecutive numbering
(2) Auto reset
(3) Manual reset
OTHER FEATURES
Custom Functions 11 Custom Functions with 34 settings
Metadata Tag User copyright information (can be set in camera)
Image rating (0-5 stars)
Intelligent Orientation Sensor Yes
Playback Zoom 1.5x – 10x enabled in 15steps
Display Formats (1) Single image with information (2 levels)
(2) Single image
(3) 4 image index
(4) 9 image index
(5) Jump Display
Slide Show Image selection: All images, by Date, by Folder, Movies, Stills
Playback time: 1/2/3/5 seconds
Repeat: On/Off
Histogram Brightness: Yes
RGB: Yes
Highlight Alert Yes
Image Erase/Protection Erase: Single image, All images in folder, Checkmarked images, unprotected images
Protection: Erase protection of one image at a time
Menu Categories (1) Shooting menu (x4)
(2) Playback menu (x2)
(3) Setup menu (x3)
(4) My Menu
Menu Languages 25 Languages
English, German, French, Dutch, Danish, Portuguese, Finnish, Italian, Norwegian, Swedish, Spanish, Greek, Russian, Polish, Czech, Hungarian, Romanian, Ukrainian, Turkish, Arabic, Thai, Simplified Chinese, Traditional Chinese, Korean and Japanese
Firmware Update Update possible by the user.
INTERFACE
Computer Hi-Speed USB
Other Video output (PAL/ NTSC) (integrated with USB terminal), HDMI mini output (HDMI-CEC compatible), External microphone (3.5mm Stereo mini jack)
DIRECT PRINT
Canon Printers Canon Compact Photo Printers and PIXMA Printers supporting PictBridge
PictBridge Yes
STORAGE
Type SD card, SDHC card or SDXC card
SUPPORTED OPERATING SYSTEM
PC & Macintosh Windows XP inc SP3 / Vista inc SP1 and SP2 (excl. Starter Edition) / 7 (excl. Starter Edition)
OS X v10.4-10.6
SOFTWARE
Browsing & Printing ZoomBrowser EX / ImageBrowser
Image Processing Digital Photo Professional
Other PhotoStitch, EOS Utility (inc. Remote Capture), Picture Style Editor
POWER SOURCE
Batteries 1 x Rechargeable Li-ion Battery LP-E8
Battery Life Approx. 440 (at 23°C, AE 50%, FE 50%) [5]
Approx. 400 (at 0°C, AE 50%, FE 50%)
Battery Indicator 4 levels
Power Saving Power turns off after 30sec or 1, 2, 4, 8 or 15mins.
Power Supply & Battery Chargers AC Adapter Kit ACK-E8, Battery charger LC-E8, LC-E8E
PHYSICAL SPECIFICATIONS
Body Materials Stainless Steel and polycarbonate resin with glass fibre
Operating Environment 0 ? 40 °C, 85% or less humidity
Dimensions (WxHxD) 133.1 x 99.5 x 79.7 mm
Weight (body only) Approx. 570g (CIPA testing standard, including battery and memory card)
ACCESSORIES
Viewfinder Eyecup Ef, E-series Dioptric Adjustment Lens with Rubber Frame Ef, Eyepiece Extender EP-EX15II, Angle Finder C
Case Semi-Hard Case EH19-L
Wireless File Transmitter Compatible with Eye-Fi cards
Lenses All EF and EF-S lenses
Flash Canon Speedlites (220EX, 270EX, 270EX II, 320EX, 420EX, 430EX, 430EX II, 550EX, 580EX, 580EX II, Macro-Ring-Lite, MR-14EX, Macro Twin Lite MT-24EX, Speedlite Transmitter ST-E2)
Battery Grip BG-E8
Remote Controller/ Switch Remote Switch RS-60E3, Remote Controller RC-6
Other Hand Strap E2
All data is based on Canon standard testing methods except where indicated.
Subject to change without notice.
[1] Large/Fine(Quality 8) resolution
[3] Compatible with large memory card capacities, including cards of 2GB and more (camera may require firmware update).
[4] With 50mm lens at infinity, -1m-1 dpt
[5] Based on the CIPA Standard and using the batteries and memory card format supplied with the camera, except where indicated
[7] With EF300mm f/2.8L IS USM at 50kph
[8] Recommended Exposure Index
